18 METRE JCB HIVIZ
18 METRE JCB HIVIZ
Unrivalled Strength And Durability
This industry leading telescopic handler offers performance and on-site safety.
The new 540-180 HiViz has a precise high-speed double boom chain extension system to maximise job site efficiency. Electro servo hydraulics and a high-flow 110 l/min hydraulic pump also ensure fast cycle times.
The unique regenerative hydraulic system, part of JCB’s SMART Technology package, harnesses gravitational forces, diverting oil back to the rams while the arm is lowering. On the 540-180 HiViz this feature helps to reduce cycle times by up to 20% and fuel consumption by 4.4%
A clever 4-piece boom design combines a hydraulic ram and chains to extend or retract all the sections proportionally in one fast, smooth movement.
- JCB’s unique regenerative hydraulics harness gravitational forces, diverting oil back to the rams while the arm is lowering. This feature helps to reduce cycle times by up to 20% and fuel consumption by 4.4%.
- With a 10% reduced turning circle than the 540-170 as well as 1000kg lighter thanks to a shortened chassis and lightweight boom sections, the 540-180 HiViz is one of the most manoeuvrable machines around.
- A JCB Construction Loadall is extremely manoeuvrable; the compact wheelbase, large steering lock angles and 3 steer modes save valuable time on site.
There’s no machine that works harder on site – with unique safety features and class leading visibility.
18 METRE JCB HIVIZ Specifications
Dimensions
Weight:
11,380 kg
Length:
6,270 mm
Width:
2,350 mm
Height:
2,590 mm
Other Specifications
Max Lifting Height:
17,510 mm
Max Lifting Weight:
4,000 kg
Standard Specifications
Aircon
Keypad Immobiliser
CD Radio
Wheel Nut Indicators
Belly Guard
Speed Restrictor
Forward Facing Camera
GPS Tracking
Site Manager Telematic Reporting
Amber & Green Beacons
Chassis Levelling
Hydraulic Forks
Optional Extras
360 Camera
Forward Facing Camera
OKO Fill
Reversing Camera
270 AI Camera System
Remove 4th Gear on Request
Road Legal
Spare Parts Kit
TPMS
Rear View Camera
